DiClad® 870 and 880 Laminates

By using fewer plies of woven fiberglass and a higher ratio of PTFE content, the DiClad 870 and DiClad 880 laminates offer lower dielectric constants (Dk) and dissipation factors at a similar thickness to other laminates in the DiClad® series.

Features

• Dk of 2.33 for DiClad 870 laminates
• Dissipation factor of .0013 at 10GHz for DiClad 870 laminates
• Dk of 2.17 or 2.20 for DiClad 880 laminates
• Dissipation factor of .0009 at 10GHz for DiClad 880 laminates

Benefits

• Lowest moisture absorption among PTFE based composites
• Stable Dk over a wide frequency range
• Low Dk supports wider line widths for lower insertion loss

Applications

View current applications of this product.

Antenna Systems

Antennas

Communications
Systems

Power Amplifiers

• Antenna Systems
• Antennas
• Communications
  Systems
• Power Amplifiers
