CLTE-MW™ Laminates

CLTE-MW laminates provide PCB designers a high performance, cost-effective material, well suited for applications with thickness limitations due to physical or electrical constraints. This unique laminate system is available in seven thickness options, from 3 to 10 mils, ensuring that ideal signal to ground spacing exists for 5G and other millimeter wave applications. The CLTE-MW laminates are reinforced with spread glass which, along with a high filler loading, helps minimize the high frequency glass weave effects on electromagnetic wave propagation.

Features

• Low loss tangent of .0015 at 10GHz
• Low Z-axis CTE of 30ppm/°C
• Thermal conductivity of .42 W/(mK)
• UL94 V-0 flammability rating

Benefits

• Enables low loss designs
• Excellent plated through hole (PTH) reliability
• Good heat dissipation in aggressive designs
• Compatible with commercial applications
• Reliable mechanical performance under thermally challenging environments

Applications

View current applications of this product.

Active Safety

Antenna Systems

Backhaul Radios

Communications
Systems

Handheld Device Cellular and Wifi Antenna

Power Amplifiers

• Active Safety
• Antenna Systems
• Backhaul Radios
• Communications
  Systems
• Handheld Device Cellular and Wifi Antenna
• Power Amplifiers
